 Mesa Series

Built from the same materials and critical components as AirBox’s larger Peak Series-S unit (which was scientifically proven to remove 99.99% of airborne pathogens, including MS2 Bacteriophage, a SARS-CoV-2 (Causes COVID-19) Proxy Virus, Mesa’s smaller design makes it the perfect fit for smaller businesses, school classrooms and indoor home spaces.

Photo Feb 05, 3 30 46 PM.heic

High-Density

Polyethylene (HYDPE)

Made in America with the highest-quality design and durable components, the Mesa enclosure is made of HDPE infused with Micro-Shield making it practically indestructible and bacteria resistant.


COVID-19 Eliminating CERTIFIED HEPA Filter

Even in a small design, the Mesa Series packs the same CERTIFIED HEPA filter as the PEAK unit which filters our 99.99% of all particle sizes including viruses, bacteria, mold, dust, odors, and pollen.


Power &

Speed Control

Controls are provided by a simple dial on the front of the motor housing. Thereby, eliminating complex electronic boards and mitigating electrical issues.

Blurred Office Interior

Product Specs

Dimensions:

  • Weight: 30.5 lbs

  • 14 3/4” W 13 1/8” H 18”

Features:

  • 110/120 Volt 6’ black power cord

  • Rotating speed control knob to adjust to the desired airflow

  • Honeycomb panels located at the bottom and top of the unit laminate the airflow to improve flow efficiency and increase exit velocity to affect Dynamic Room Air Purge.

  • Convenient Sliding Access Panel for easy filter changes

  • Made to operate 24/7

  • Pre-Filters recommended being changed every 3 months, HEPA every 2 years.

  • Fan Motor UL Listed 2111

Enclosure:

  • High Density Polyethylene (HDPE) treated with MicroShield Antimicrobial

  • Made from FDA, USDA Approved materials. Meets ASTM D4976

  • Contains NO VOCs. Flammability Rating: UL94-HB

  • Constructed with Stainless Steel Fasteners

Color:

  • Available in White or Dolphin Gray

Electrical:

  • This unit is wired for 110/120 Volt Operation

  • Wiring: AWG16

  • Connectors: Deutch DT IP68 Dust & Water (submersion to 3m)

  • Controls: Single Commercial-Grade Potentiometer

  • Motor: 115VAC, 50/60HZ, Ball Bearing, IP54 Dust & Water

Filtration:

  • HEPA Filter (Final Filter Stage)

    • Certified 99.99%

    • 4" Pleated Glass Media

    • Aluminum Frame

Antimicrobial Filter (First Filter Stage)

  • Merv 11 2" Electrostatically Charged Pleated Polyester

  • Treated with Microban Aegis Microbe Shield®



Warranty:

  • Limited Lifetime Warranty. Lifetime Warranty on material and workmanship.

  • 5 Year warranty on fan and motor package inclusive of electrical.

Performance Specifications

"The Sound You Hear Is the Sound of Clean"

mesa specs chart.PNG
