Mesa Series

Built from the same materials and critical components as AirBox’s larger Peak Series-S unit (which was scientifically proven to remove 99.99% of airborne pathogens, including MS2 Bacteriophage, a SARS-CoV-2 (Causes COVID-19) Proxy Virus, Mesa’s smaller design makes it the perfect fit for smaller businesses, school classrooms and indoor home spaces.

High-Density
Polyethylene (HYDPE)
Made in America with the highest-quality design and durable components, the Mesa enclosure is made of HDPE infused with Micro-Shield making it practically indestructible and bacteria resistant.

COVID-19 Eliminating CERTIFIED HEPA Filter
Even in a small design, the Mesa Series packs the same CERTIFIED HEPA filter as the PEAK unit which filters our 99.99% of all particle sizes including viruses, bacteria, mold, dust, odors, and pollen.

Power &
Speed Control
Controls are provided by a simple dial on the front of the motor housing. Thereby, eliminating complex electronic boards and mitigating electrical issues.

Product Specs
Dimensions:
-
Weight: 30.5 lbs
-
14 3/4” W 13 1/8” H 18”
Features:
-
110/120 Volt 6’ black power cord
-
Rotating speed control knob to adjust to the desired airflow
-
Honeycomb panels located at the bottom and top of the unit laminate the airflow to improve flow efficiency and increase exit velocity to affect Dynamic Room Air Purge.
-
Convenient Sliding Access Panel for easy filter changes
-
Made to operate 24/7
-
Pre-Filters recommended being changed every 3 months, HEPA every 2 years.
-
Fan Motor UL Listed 2111
Enclosure:
-
High Density Polyethylene (HDPE) treated with MicroShield Antimicrobial
-
Made from FDA, USDA Approved materials. Meets ASTM D4976
-
Contains NO VOCs. Flammability Rating: UL94-HB
-
Constructed with Stainless Steel Fasteners


Color:
-
Available in White or Dolphin Gray
Electrical:
-
This unit is wired for 110/120 Volt Operation
-
Wiring: AWG16
-
Connectors: Deutch DT IP68 Dust & Water (submersion to 3m)
-
Controls: Single Commercial-Grade Potentiometer
-
Motor: 115VAC, 50/60HZ, Ball Bearing, IP54 Dust & Water
Filtration:
-
HEPA Filter (Final Filter Stage)
-
Certified 99.99%
-
4" Pleated Glass Media
-
Aluminum Frame
-
Antimicrobial Filter (First Filter Stage)
-
Merv 11 2" Electrostatically Charged Pleated Polyester
-
Treated with Microban Aegis Microbe Shield®
Warranty:
-
Limited Lifetime Warranty. Lifetime Warranty on material and workmanship.
-
5 Year warranty on fan and motor package inclusive of electrical.
